Cross section Allison style transmission.
![](https://cdn.myportfolio.com/e48907d1-bf9c-4fbc-be11-1e00616919f7/a457f317-88df-41b0-aae3-19e0c78376b8_rw_1200.jpg?h=920442291d1fa8ca9db1eca8e12f9cb2)
Cross section of an allison style transmission.
Final illustration as used in advertising, collateral, web and trade show.
![](https://cdn.myportfolio.com/e48907d1-bf9c-4fbc-be11-1e00616919f7/9220ac41-bb1a-4f20-a0a9-8ec53908f994_rw_1200.jpg?h=e64165e43e646459b4bbf538721b7bfa)
Just an invertion os the final transmission, I prefer it this way.
![](https://cdn.myportfolio.com/e48907d1-bf9c-4fbc-be11-1e00616919f7/ecd9f2bf-249a-4c14-94db-d3eecb7e8311_rw_1200.jpg?h=661b04a539680b7e0ad014dcae06fdae)
Line art generated in Adobe illustrator.
